High Quality 67.2V 20A 15A 10A 8A 5A Lithium Li-ion Battery Charger Power Supply Fast Output 180V-240V 60V Ebike E-Bike Electronic Car
Product Introduction
We will continue to improve and strengthen our quality management system to ensure that our Golf Cart Battery Charger, 72v On Board Sweeper Charger, 72v Sweeper Charger meets advanced international standards. If we want to improve the performance of enterprises, we should treat the symptoms rather than the root cause from the external factors, and the key is to improve the core competitiveness of enterprises. We focus on cultivating the ability of implementation and improving the system and environment of corporate social responsibility. We regard innovation as the soul of corporate progress and the inexhaustible power of our foundation, and our employees are the source of innovation.
Overview of ATV Charger
Looking for a charger that's small, efficient, and tough? Look no further than the 72v ATV Onboard Charger! This charger is perfect for keeping your battery healthy and fully charged. It features soft-start pre-charging to prevent damage to the battery, as well as pulse repair charging to help revive over-discharged batteries. Plus, it has an IP 66 rating so it can withstand any weather conditions. Don't go on your next ride without one!
The 72v ATV Onboard Charger is perfect for keeping your vehicle running smoothly. It's small size and high IP rating make it a great choice for vehicles with sensitive electrical systems, while its high charging efficiency means you can get back on the road faster. Plus, soft-start pre-charging protects your battery from damage caused by large current impacts, and pulse repair charging helps to restore energy levels if the battery is over-discharged.
Specifications of 72V ATV Onboard Charger
| Specifications | Input Voltage Range | Rated Output Voltage | Max Output Voltage | Max Output Current |
| SMHC3-4842A | AC90-264V | 48V | 66V | 42A |
| SMHC3-6040A | AC90-264V | 60V | 82.2V | 40A |
| SMHC3-7240A | AC90-264V | 72V | 99V | 40A |
| SMHC3-8440A | AC90-264V | 84V | 110V | 40A |
| SMHC3-9632A | AC90-264V | 96V | 132V | 32A |
| SMHC3-12025A | AC90-264V | 120V | 165V | 25A |
| SMHC3-14423A | AC180-264V | 144V | 198V | 23A |
| SMHC3-31210A | AC90-264V | 312V | 440V | 10A |
Parameters of 72V ATV Onboard Charger
| Item | Parameters |
| AC Input Wide Voltage,Range | AC90-264V |
| AC Input Frequency Range | 40-70Hz |
| With APFC Function,Power Factor | ≥0.98 |
| Soft Switching Technology,Efficiency | ≥93% |
| Protection Level | IP67 |
| Operating Temperature | -40℃~+60℃ |
| Storage Temperature | -55℃~+100℃ |
| CAN Communication Function | Optional |
| 12v3a Auxiliary Power Supply | Optional |
| LED Light Indicator for Charging Process | Standard |
| Noise | ≤45dB |
| Overall Size | 294x210x111(mm) |
| Net Weight | 5.9kg |
Advantages of 72V Onboard Battery Charger
