48 Volt Golf Cart Battery Charger
Overview of 48 volt golf cart battery charger
This 48 volt golf cart battery charger is a perfect product for those who are looking to charge their batteries.The 48 volt golf cart battery charger offers protection features to keep your equipment safe while charging. The output over voltage protection will shut off the charger if it becomes too high, and the output over current protection will do the same if it becomes too high. The output short circuit protection kicks in if there is a problem with the wiring, and the output reverse protection keeps the battery from being damaged in case of an incorrect connection. Plus, the charger has over temperature protection to prevent both itself and the battery from overheating.
The protection features on this charger include over voltage, output current, reverse and short circuit protection. It also has an over temperature feature that will protect the battery from being overcharged or overheating. This product can be used with any 48-volt lead acid battery type which includes 6-, 8-, 12-volt lead acids. So if you are looking for a great way to charge your batteries then this would be the best choice!
Advantages of 48 volt golf cart battery charger
Input plugs & output connectors of 48 volt golf cart battery charger
More plugs and connectors pls click here
Technical Characteristics of 48 volt golf cart battery charger
Item | Parameters |
AC Input Wide Voltage Range | AC90-264V |
AC Input Frequency Range | 40-70HZ |
With APFC Function Power Factor | ≥98% |
Soft Switching Technology Efficiency | ≥93% |
Protection Level | IP67 |
Operating Temperature | -40℃-+60℃ |
Storage Temperature | -55℃-+100℃ |
CAN Communication Function | Optional |
12V3A Auxiliary Power Supply | Optional |
LED Light Indicator for Charging Process | Standard |
Noise | ≤45dB |
Overall Size | 282x146x82mm |
Net Weight | 2.7kg |
Protection Functions of 48 volt golf cart battery charger
| Overheat Protection | When the internal temperature of the charger exceeds 80℃,the charging current will reduce automatically.When it exceeds 85℃,the charger shutdown for protection.When the teamperature drop,the charger automatically resumes to charge. |
| Short Circuit Protection | When the output short circiut ,the charger will automatically shutdown the output.After troubleshooting,the battery can be reconnected to resume charging. |
| Battery Reverse Connection Protection | When the battery is reverse connected,the internal circiut of the charger will automatically disconnect from the battery,without charging,without damaging the charger. |
| Inpiut low-voltage & Over-voltage Protection | If the input voltage is lower than 150v or higher than 264v,the charger will shutdown protectively and automatically resume working with the voltage is normal again. |
| Full Automatic Shutdown | Automatically shut down after full charge |
