96V Lead Acid Charger
✱Input Voltage Range:AC90-264V,
✱Output Voltage:DC 12V/24V/36V/48V/60V/72V/96V,
✱Input/Output Plug(optional),
✱Charging Indicator(optional),
✱CAN BUS or not(optional),
✱Size:282x168x90cm,
✱Net weight:3.8kg(8.3lb),
Send Inquiry
Product Details of96V Lead Acid Charger
Overview
Let us understand the Lead-acid Battery:
Lead-acid battery electrodes are mainly made of lead and its oxides. The electrolyte is a battery of sulfuric acid solution. At present, lead-acid battery chargers have developed to the fifth generation, and the latest upgraded version of the charger is protected by the fourth-generation relay. On the basis of more advanced integrated IC computer chip control system, the technology is more advanced, and the charging process is more intelligent; it has a wide range of charging voltage and battery capacity, battery saturation prevention overcharge, short circuit automatic protection, high safety factor, low heat, High efficiency, no damage to the battery, small size, light weight and easy placement.
Features of lead acid charger
1: Summit is a charger specially designed for small lead-acid batteries, with a wide input voltage AC90-264V;
2: The output is two alligator clips, positive and negative ends, when charging, clip the wrong poles, automatic protection, short circuit protection (no sparks);
3: The blue light is on when charging, and the red light is on when fully charged;
4: Not afraid of short circuit and wrong connection, short circuit, overload, overcurrent, reverse connection automatic protection, extremely high safety factor, small heat and high efficiency.
 |
 |
Specifications
| Models | Input voltage range | Rated voltage range | Max output voltage | Max output voltage |
| SMCZ2-1230A/1230C | AC90-264V | 12V | 20V | 45A |
| SMCZ2-2445A/2440C | AC90-264V | 24V | 33V | 40A |
| SMCZ2-3640A/3640C | AC90-264V | 36V | 49.5V | 35A |
| SMCZ2-4835A/4825C | AC90-264V | 48V | 66V | 35A |
| SMCZ2-6030A/6020C | AC90-264V | 60V | 82.5V | 30A |
| SMCZ2-7225A/7218C | AC90-264V | 72V | 99V | 25A |
| SMCZ2-8022A | AC180-264V | 80V | 110V | 22A |
| SMCZ2-9610A/9610C | AC90-264V | 96V | 132V | 10A |
Technical Paraments
| Item | Prameters |
| AC Input Wide Voltage Range | AC90-264V |
| AC Input Frequency Range | 40-70HZ |
| With APFC Function Power Factor | 0.98 |
| Soft Switching Technical Efficiency | 93% |
| Protection Level | IP67 |
| Operating Temperature | -40℃~+60℃ |
| Storage Temperature | -55℃~+100℃ |
| CAN Communication | Optional |
| 12V3A Auxiliary Power Supply | Optional |
| LED Light Indicator for Charging Process | Standard |
| Noise | <46dB |
| Overall Size |
282 ×168× 90 (mm)
|
| Net Weight | 3.8kg |
Application
|
|
