The Benefit of a Charger With CAN Communication
CAN is an open network protocol that allows communication between different devices in the same or a separate network. It is used for vehicles, electrical equipment and more.
Battery chargers can be integrated with CAN bus to communicate with the battery management system, which monitors battery voltage and temperature and controls the charging process.
Lithium Battery Charging
Lithium batteries are becoming more popular in a variety of applications, including electric vehicles and other industrial machinery. They offer a number of benefits, including small size, lightweight, high-temperature performance and high recharge rate.
Chargers with CAN communication allow for real-time monitoring and control of the battery’s performance, reduced wiring complexity, efficient use of resources, enhanced safety, and scalability. They also reduce the risk of accidents or fires caused by malfunctioning batteries.
A charger with CAN communication can be controlled by the BMS, which is a central battery management system (BMS) in the vehicle that manages all electrical functions for the car. The BMS can then use CAN communication to send commands to the charger to regulate charging, discharging and temperature.
The BMS will then use the CAN communication to update the charging algorithm and charger software, ensuring the battery is charged at its highest level of efficiency. It can also provide fleet operators with telematics data, giving them information on battery health and allowing them to conduct field fixes remotely.
As the lithium cell is more complex than other types of batteries, it is important to use a specialist charger that can deal with its unique challenges. Using a charger that does not have the necessary features can result in damage to the battery and loss of efficiency.
In addition, the voltage and current used for charging lithium cells can be different than that of a lead acid battery. The voltage of the battery can become too high, causing chemical combustion and damage to the cell or even the entire battery pack. This is why it is essential to use a professional, approved charger with the right voltage and current for your application.
Over-temperature protection is another important feature for a charger that can handle lithium batteries. This is especially important for applications that require a large number of recharge cycles, such as an electric bike or automatic carrier, which can be prone to thermal runaway.
In order to prevent this, the charger must be able to cut off the charge as soon as it reaches a fully-charged state, which can be done quickly by switching off the power supply and then cutting the current. This is the key to protecting the lithium battery from overcharging and ensuring that it does not become a fire hazard.
Battery Management Systems (BMS)
A charger with CAN communication is a great addition to a BMS. It can communicate with a charging station and help to monitor the battery's condition, including its current, voltage, and temperature. This data can be used to help determine if a battery pack is healthy or if it needs repair.
A CAN bus network is also helpful for storing data collected during testing. This gives you the ability to review, store, and compare the results from your testing equipment with the results from your battery management system. CAN is also compatible with a variety of battery types, so it is a great option for many different applications.
Cell protection
The first major feature of a battery management system is cell protection, which prevents the battery from operating beyond its design limits. This includes protecting the battery from overcharging, over-temperature conditions, and other factors that can damage a battery.
Another important feature of a BMS is charge control, which helps protect a battery from being overcharged or discharged below its designed limits. The BMS may automatically reduce the charge rate as it approaches these limits, and may terminate the charge if it reaches the limit.
For EVs or HEVs, the BMS must also be very accurate at calculating the remaining range of a battery, which is based on the battery's state of charge (SOC), its energy consumption, and how far the battery has been used in the past. Using this information the BMS can determine how many miles it should be able to travel before recharging is required.
Thermal management
A lithium-ion battery is sensitive to temperature, especially when charging is involved. Temperature can cause memory effects and significant capacity loss, so a battery management system should be capable of ensuring that the battery is charged only when it is in the Goldilocks temperature range for optimal performance during operational usage.
In some cases, a BMS can also engage external in-line heaters and turn-on resident heater plates to elevate the temperature of a battery before charging begins. These features are especially useful in cases where the battery packs are incorporated into a vehicle, such as an electric vehicle or a helicopter.
Intelligent Battery Charging
When an electric vehicle (EV) is plugged in at a smart charging point, the charger automatically sends information to a cloud-based platform. This data is used to optimize how an EV charges and to monitor energy usage at the charging site.
Battery-to-charger communication is done using a standard communication protocol known as the System Management Bus (SMBus). The SMBus is a concerted effort by many manufacturers to agree on one communications protocol and one set of data that can be used in any EV charger.
These communication protocols allow the charger to adapt its charging profile to various types of batteries based on their specific chemistry, voltage and capacity. Some charge profiles are designed to optimize the battery's performance, while others are created to ensure that the battery remains in the safest and most reliable state of charge possible.
Most smart chargers also use a combination of cut off systems to prevent overcharging. Typically, an intelligent battery charger fast-charges a battery up to 85% of its maximum capacity in less than an hour. Then, it switches to trickle charging to maintain the battery's charged status.
This can help extend the life of your battery by ensuring that it's never overcharged. It can also help you avoid going over your energy limit, which can result in an extra bill from your electricity provider.
Another important feature of a smart battery charger is Power Boost, which prevents you from exceeding your home's maximum energy capacity. By dynamically balancing the load among the charger and other devices in your home, Power Boost helps you avoid these extra costs.
As the batteries themselves are becoming more intelligent, they can start to communicate with the chargers through their BMS (Battery Management Systems). These BMSs can provide the battery with specific charge parameters by communicating via CAN remote control.
These messages can be sent to the charger to change the charge parameters if the battery's temperature becomes too high or if it's reaching a critical stage of the charge process. These CAN remote control messages can also be used to notify the charger of other important battery attributes, such as cell-to-cell voltage fluctuations.
Integration
CAN is an open communication protocol that allows a variety of electronic devices to communicate with each other. CAN is used across many industries, including automotive, manufacturing, and building automation. It has multiple benefits over traditional analog signals, such as speed, ease of integration, and low cost.
Unlike older wiring standards, CAN utilizes a two-wire communication system, which greatly reduces the amount of wire needed for communication. This also helps to ensure the integrity of the data transmission process and reduces the risk of interference from outside sources.
The CAN standard has several features that make it ideal for safety applications such as vehicles. These include:
Fault tolerance: All CAN nodes have their own error counters, which detect errors in the transmission of data and automatically shut down the device when one is detected. This prevents a single malfunction from spreading throughout the system and causing it to stop functioning entirely.
This is done by sending a special Error Flag message. Once the error has been detected, CAN nodes will destroy the offending data to prevent further transmission.
Error detection: CAN has 5 mechanisms to detect errors in the data transmission process. These include bit stuffing, bit monitoring, frame check, acknowledgment check, and cyclic redundancy check.
Another important feature of CAN is its ability to weed out unwanted high-frequency noise from the bus lines by using a termination technique that filters it out with a capacitor between two termination resistors. This technique is typically used in applications with long cable runs and improves electromagnetic compatibility of the network.
CAN is scalable and has the potential to grow into a wide array of applications. Its speed, ease of integration, and low cost have made it a popular choice for manufacturing environments as well as building automation.
However, CAN is not without its drawbacks. Its limited bandwidth and range, complex integration, security vulnerabilities, and compatibility issues may pose challenges in some situations. These issues can be addressed with newer versions of the CAN protocol and proper network design and security measures.
